SimMan ALS

Træning i høj kvalitet og realistisk ALS

Adding realism to in-situ training

SimMan ALS provides a mobile, durable and affordable solution that will meet the training needs of pre-hospital and in-hospital emergency care providers - from basic assessment to advanced life-support skills.

From pre-hospital, on-scene assessment and management to definitive care in a hospital, SimMan ALS can fulfill the unique training requirements of emergency healthcare providers.

Enhanced defibrillation training with ShockLink or LiveShock

SimMan ALS LiveShock

SimMan ALS LiveShock is a combination of a unique SimMan ALS chest skin and an integrated ShockLink unit that enables the use of a live defibrillator with real pads or paddles. No need for separate training pads or paddles.

SimMan ALS with ShockLink

Pairing SimMan ALS with ShockLink (bought separately) enables the use of a live defibrillator with training pads. Training events will automatically be captured in the SimPad PLUS or LLEAP data log for assessment and debrief.

For both options, training events such as time spent administering CPR, to placing the pads correctly and delivering a shock with minimal interruptions will automatically be captured in the SimPad PLUS or LLEAP data log for assessment and debrief.

Drifts- og debriefingmuligheder

Uanset om du anvender SimPad PLUS eller en LLEAP-PC til at styre din simulation, er softwaren både brugervenlig og effektiv til scenariebaseret træning. De intuitive platforme giver fleksibel kontrol over patientparametre, mulighed for integreret data- og videooptagelse samt simuleret patientovervågning.
Vælg den løsning, der bedst understøtter dine træningsbehov.

Tag din simulationstræning til næste niveau

SimMan Trauma kan indgå som en del af en mere omfattende løsning, der yderligere styrker træningen af kliniske færdigheder.

Robust og problemfri simulationsdrift

Oprethold driftssikkerhed og vær altid opdateret med den nyeste viden om simulation gennem support fra Laerdals omfattende portefølje af tekniske og uddannelsesmæssige serviceydelser.

SimMan ALS leverer en mobil, holdbar løsning, der opfylder træningsbehovene for præhospital- og hospitalspersonale inden for akut pleje - fra grundlæggende vurdering til avancerede livsredningsfærdigheder.

Specifications

Anterior and posterior lung sounds

CPR measurement capture and review

Cyanosis linked to vital signs

Pneumothorax with unilateral chest movement

Prepared for ultrasound diagnostic and enhanced defibrillation training

Vascular access - IV and IO



Completely wireless and self-contained

  • Internal electrical and pneumatic power
  • Supplemental wired connectivity and power
  • Wirelessly integrates with existing computer networks
  • Possibility to attach an additional battery on the side to extend the use
  • Rugged and reliable for use in multiple environments



Multiple Airway Skills/Features:

  • Controllable open/closed airway; automatically or manually controlled
  • Head tilt/Chin lift
  • Jaw thrust w/articulated jaw
  • Suctioning (Oral & Nasopharyngeal)
  • Bag-mask ventilation
  • Orotracheal intubation
  • Nasotracheal intubation
  • Combitube, LMA, I-gel and other airway placement
  • Endotracheal tube intubation
  • Retrograde intubation
  • Fiberoptic intubation
  • Transtracheal jet ventilation
  • Needle cricothyrotomy
  • Surgical cricothyrotomy
  • Airway resistance - 3 settings (On/Off/Half)
  • Right main stem intubation
  • Stomach distention



Airway Complications:

  • Tongue fallback
  • Tongue edema



Breathing Features:

  • Simulated spontaneous breathing
  • Bilateral and unilateral chest rise and fall
  • Normal and abnormal breath sounds
  • Lung auscultation sites: posterior and anterior sites
  • Oxygen saturation and waveform



Breathing Complications:

  • Cyanosis
  • Needle thoracentesis – bi-lateral
  • Unilateral & Bilateral chest movement
  • Chest tube insertion – bilateral



Cardiac Features:

  • Extensive ECG library
  • Heart sounds
  • ECG rhythm monitoring (4 wire)
  • 12 lead ECG display
  • Defibrillation and cardioversion with live shock – Laerdal LINK technology
  • Pacing



Circulation Features:

  • BP measured manually by auscultation of Korotkoff sounds
  • Carotid, femoral, radial pulses synchronized with ECG
  • Pulse strength variable with BP
  • Pulse Palpation is detected & logged



Vascular Access:

  • IV access (right arm)
  • Intraosseous access (tibia)



CPR:

  • Compliant with 2010-2015 Guidelines
  • CPR compressions generate palpable pulses, blood pressure wave form, and ECG artefacts
  • Realistic compression depth and resistance
  • Detection of depth, release and frequency of compressions



Eyes:

  • Manually set to: Open, closed and partially open
  • Set of interchangeable pupils



Other Features:

  • Foley catheterization without urine output
  • Pre-prepared for use of the SonoSim Ultrasound solution
  • Patient Voice
    • Pre-recorded sounds
    • Custom sounds
    • Instructor can simulate patient’s voice wirelessly



System Features:

  • Wireless tablet PC controls simulator remotely or SimPad Plus system
  • Control simulations from anywhere on your network
  • Manual Mode
    • Precise control “on the fly”
  • Automatic Mode
    • Run pre-packaged scenarios
    • Unique, simple controls increase/decrease difficulty & pace
  • Integrated video debriefing
  • Data logging
  • Instructor comments
  • Scenarios available on Laerdal Scenario Cloud



Patient Monitor:

  • Wireless
  • Highly configurable
  • Includes (depending on the operating system):
    • ECG (2 traces)
    • SpO2
    • CO2
    • ABP
    • CVP
    • ICP
    • Anesthetic Agent
    • PH
    • PTC
    • PAP
    • PCWP
    • NIBP
    • TOF
    • Cardiac Output>
    • Temperature (core & peripheral)
    • Additional and programmable



Parameters:

  • 12 Lead ECG Display



LLEAP

  • X-Ray Display
  • Custom Image Display
  • Custom Video Display





SimMan ALS includes:

  • SimMan ALS Manikin
  • 2 Soft Sided Transportation Cases
  • Specially Designed Clothing
  • 1 Year Manufacturer’s Warranty



Accessories:

  • Operating system:
    • LLEAP PC or SimPad Plus®
    • Simulated Patient Monitor & Software
    • Scenarios are available on Laerdal Scenario Cloud



Service Packages*:

  • One or 2 Day Introductory Training Course
  • Advanced Scenario Programming Course
  • Custom One Day Training Package
  • Custom Scenario Development Package
  • On Site Installation
  • Extended Warranty
  • Preventative Maintenance
  • Loaner Program

* services available may differ between countries
